DDG-0.1F&0.01F Industrial Tri-clamp Conductivity Sensor

1. Constant of electrode: 0.1, 0.01
2. Compressive strength: 0.6MPa
3. Measuring range: 0.01-20uS/cm, 0.1~200us/cm
4. Connection: hard tube, hose tube, flange installation
5. Material: 316L stainless steel, Titanium Alloy and Platinum
6. Application: Fermentation, Chemical, Ultra-pure water

Conductivity is a measure of water’s capability to pass electrical flow. This ability is directly related to the concentration of ions in the water 1. These conductive ions come from dissolved salts and inorganic materials such as alkalis, chlorides, sulfides and carbonate compounds 3. Compounds that dissolve into ions are also known as electrolytes 40. The more ions that are present, the higher the conductivity of water. Likewise, the fewer ions that are in the water, the less conductive it is. Distilled or deionized water can act as an insulator due to its very low (if not negligible) conductivity value 2. Sea water, on the other hand, has a very high conductivity.

Ions conduct electricity due to their positive and negative charges 1. When electrolytes dissolve in water, they split into positively charged (cation) and negatively charged (anion) particles. As the dissolved substances split in water, the concentrations of each positive and negative charge remain equal. This means that even though the conductivity of water increases with added ions, it remains electrically neutral 2
